Metallux Hall potentiometer
POH 120
产品描述
The POH 120 is small and robust and features a freely programmable rotary angle. The measurement principle is
via Hall effect as abso-lute measuring rotary sensor even after blackout. The POH series is available with a
decoupled axis or integrated axis.
-Long lifetime
-Size Ø 13mm
-Valve controls
-Joysticks
-Steering angle measurement
-Servo systems
-Hall sensor
-Compensation for play and tolerance by decoupled axis possible
-Freely programmable angles possible
-load free engine when axis is uncoupled
