Metallux Hall potentiometer

Metallux Hall potentiometer

POH 120


The POH 120 is small and robust and features a freely programmable rotary angle. The measurement principle is
via Hall effect as abso-lute measuring rotary sensor even after blackout. The POH series is available with a

decoupled axis or integrated axis.



-Long lifetime

-Size Ø 13mm



-Valve controls
-Steering angle measurement

-Servo systems



-Hall sensor
-Compensation for play and tolerance by decoupled axis possible
-Freely programmable angles possible

-load free engine when axis is uncoupled
