Metallux Conductive-plastic precision potentiometer

Metallux Conductive-plastic precision potentiometer

POL 230


The single-turn precision potentiometer with conductive plastic technology and a servo flange features a robust aluminum housing as well as ball bearings to protect it from high mechanical stress. The cable, wire or pin connection is sealed. The axis diameter can be selected from a range of 3–6.35 mm. The POL 230 also features a long lifetime and good linearity.



-Long lifetime

-Good linearity



-High quality measuring systems
-Servo systems
-2x ball bearing
-Diameter: 22 mm
-Lifetime: 20 million cycles, redundant versions,special versions possible














Corresponding parameter set not found, please add it in property template of background
