Agent Products

Metallux Power Resistors

PLR 100,200,300,900


The space-saving design of power resistors made using thick-film technology on steel substrates makes it
possible to achieve high capacity, even in the narrowest spaces. Special features including extremely low inductance and high resistance values open new per-spectives in power electronics. Variable resistance values,
in addition to standard dimensions, freely selectable geometries upon request, as well as universal connection variants, optimally round out the product family of Metallux power resistors.



-Low inductive
-Simple mounting
