Metallux Potentiometric conductive plastic linear position sensor

Metallux Potentiometric conductive plastic linear position sensor



As an absolute linear position sensor with robust design and a 3 or 4 mm push rod, the Metallux linear position sensor features conduc-tive plastic technology, a long lifetime and easy installation. The mechanical coupling
is by threaded connectors. The measuring range is from 25 mm to 300 mm. Customised versions according to
customer specific requirements can be offered.
The potentiometric conductive plastic position sensor WPL is available in different designs.
Customized modifications can be realized at any time.

On request available with return spring.



-Long lifetime
-Easy mounting


-Displacement probes
-Cylinder stroke measurement
-Foot pedal position

-Valve control














Corresponding parameter set not found, please add it in property template of background
