Metallux Conductive plastic potentiometer

Metallux Conductive plastic potentiometer

POL 120


The Metallux single-turn potentiometer POL 120, with its robust design, is one of the smallest conductive
plastic potentiometers (Ø 13 mm) and features a long lifetime, a wire outlet and good linearity. The servo

flange makes precision installation possible.



-Servo flange international standards
-Long lifetime
-Good linearity

-Size Ø 13 mm



-Valve controls
-Steering angle measurement

-Servo systems



-Diameter: 13 mm
-Lifetime: 3 million cycles

-Connection: Cable wires














Corresponding parameter set not found, please add it in property template of background
